Full Enclosure Single Platform Fiber Laser Cutting Machine

Short Description:

Full enclosure single platform fiber laser cutting machine built for sheet metal shops that need clean air, safe operation and fast loading. The sealed cabin contains laser radiation and sparks, while 8 to 30 automatic dust extraction zones pull smoke out of the cutting area instead of letting it spread across the workshop.

Working area 3000×1500 mm (KC3015S), laser power 1500W / 3000W / 6000W, positioning accuracy ±0.03 mm and up to 110 m/min maximum linkage speed. A drawer-type worktable shortens loading time, which makes the machine a practical fit for electrical enclosures, precision sheet metal, kitchenware and automotive parts.

  • High load, deformation resistant
  • Dual‑bus servo motor
  • Ergonomic drawer‑type worktable
  • Smart multi‑zone dust extraction
  • High dynamic crossbeam






Recommended Cutting Thickness by Material and Laser Power

Material1500W3000W6000W
Carbon steel1-4 mm1-10 mm1-16 mm
Stainless steel1-3 mm1-5 mm1-8 mm
Aluminum1-2 mm1-4 mm1-6 mm
Galvanized steel1-2 mm1-4 mm1-6 mm

Recommended thickness range for production cutting with clean edges. Actual results vary with material quality, assist gas and required edge finish.

1Robust High-Strength Architecture
Welded steel machine bed of the KC3015S enclosed fiber laser cutting machine
The combination of dual-bus servo motors and a high-rigidity crossbeam dramatically enhances anti-vibration performance. This setup provides a reliable, high-torque power source for continuous, heavy-duty cutting operations without compromising stability.
2Ergonomic Drawer-Type Worktable
Drawer-type worktable extended for fast loading on the enclosed laser cutting machine
Featuring an intuitive drawer-style table design, this system simplifies loading and unloading, significantly reducing labor intensity and cycle times. It is the ideal solution for businesses transitioning toward smart, automated production workflows.
3Smart Multi-Zone Dust Extraction System
Multi-zone dust extraction points along the worktable of the full enclosure laser cutter
Equipped with 8 to 30 automated high-suction extraction zones, ensuring smooth smoke exhaust and superior air purification. This eco-friendly, intelligent design maintains a clean and safe workspace while effectively lowering operational energy costs.
4High-Dynamic Optimized Crossbeam
High-rigidity crossbeam with fiber laser head of the KC3015S single platform machine
Designed with a low center of gravity and a large cross-section, the beam enables rapid acceleration and maximized throughput per hour. Crafted from lightweight yet high-strength aerospace materials, it offers exceptional deformation resistance and maintains long-term mechanical precision.

TECHNICAL PARAMETERS

Machine Model KC3015S
Working Area 3000mm*1500mm
Laser Power 1500W/3000W/6000W
X/Y Pos. Accuracy ±0.03mm
X/Y Rep. Pos. Accuracy ±0.02mm
Max. Linkage Pos. Speed 110m/min
Max. Acceleration 1.5G
Rated Volt. & Freq. 3PH 380V 50Hz



Suitable Industries Electrical enclosures, precision sheet metal, kitchenware, automotive accessories, clean workshops.



Application Scenarios Medium-batch stable processing; dust-controlled environment; semi-enclosed safe operation; easy loading and unloading.

FAQ

Q: What thickness can the fully enclosed single platform machine cut?
A: With a 6000W source the recommended range is 1-16mm carbon steel and 1-8mm stainless steel. See the cutting thickness table above.

Q: What is the difference between this machine and the open single platform series?
A: Both use the same KC3015S single platform structure and the same accuracy. This model adds a full enclosure with observation windows that contains sparks, smoke and laser radiation, so it suits workshops with strict safety and air quality requirements.

Q: What working area and laser power options are available?
A: The standard working area is 3000 × 1500 mm (KC3015S), with 1500W, 3000W or 6000W laser source options. See the technical parameters table above.

Q: How does the multi-zone dust extraction system work?
A: 8 to 30 automatic high-suction extraction zones sit under the cutting area and open only where cutting takes place, so smoke is pulled out at the source instead of spreading through the workshop. This also lowers the energy cost of extraction.

Q: What accuracy and speed can the machine achieve?
A: X/Y positioning accuracy ±0.03mm, repeat positioning accuracy ±0.02mm, maximum linkage speed 110m/min and maximum acceleration 1.5G.

Q: Is the enclosed cabin safe, and does it make maintenance harder?
A: The sealed cabin blocks laser radiation and sparks, and the observation windows let operators watch the cut without opening the door. Daily maintenance is limited to cleaning the extraction filter and keeping the drawer-type worktable rails clean, so there is no extra workload compared with an open machine.

Q: Can you customize the voltage for my country?
A: Yes. 3PH 380V 50Hz is the standard configuration; other voltages and configurations are available for overseas markets.

Q: What is the price and delivery time?
A: Price depends on laser power and configuration, and delivery is normally 30-40 days after deposit. Send your material, thickness and sheet size and we will reply with an exact quotation within 24 hours.

Q: Can I test my material before purchasing?
A: Yes. Send your material type, thickness and cut quality requirement to KAFE CNC and we will arrange a sample cutting test before you place the order.
